SD motor type: 1CV3317C low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Performance Line Premium Efficiency IE3, in EEA: minimum efficiency according to (EU) 2019/1781 is IE4 (as of 01.07.2023) 6-pole * size 315L* 200 kW (50 Hz) standard color RAL 7030 if no order code is specified for selecting another color

SD Add motor type: 1CV3-405B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Premium Efficiency IE3, 4-pole * size 400 * 630 kW (50 Hz) standard color RAL 7030 if no order code is specified for selecting another color. Purchase of this product is exclusively governed by the Innomotics T&Cs located at https://www.innomotics.com/ terms-and-conditions 3AC 50 Hz 400VD/690VY * 3AC 60 Hz 460VD IM B 3, 3 PTC thermistors for disconnection (2 terminals)

MOTOR, 3,1200, SD100IEEE, 575,213T, NP, ED7, MOTOR210 SD100 IEEE – AL ROTOR

Siemens intends to sell the LV NEMA motor business to ABB on the target date of May 2nd 2023 . LOW-VOLTAGE MOTOR, NEMA 3 PHASE SQUIRREL CAGE MOTOR SEVERE DUTY SD100 IEEE 841 CAST-IRON HOUSING NP EFFICIENCY TEFC (IP55) 2 POLE * FS 449TS 200 HP (60 HZ) 460V STD, 60HZ FOOT MOUNTED F-1,2 WITHOUT WINDING PROTECTION FLOOR F-1

LOW-VOLTAGE MOTOR, NEMA 3 PHASE SQUIRREL CAGE MOTOR SEVERE DUTY SD100 IEEE 841, CAST-IRON HOUSING NP EFFICIENCY TEFC (IP55) 2 POLE * FS 143T 1.5 HP (60 HZ) 460V, 60HZ C-FACE WITH FEET WITHOUT WINDING PROTECTION FLOOR F-1

LOW-VOLTAGE MOTOR, NEMA 3 PHASE SQUIRREL CAGE MOTOR SEVERE DUTY SD100 CAST-IRON HOUSING NP EFFICIENCY TEFC (IP55) 6 POLE * FS 286T 20 HP (60 HZ) 230/460V, 60HZ FOOT MOUNTED F-1,2 WITHOUT WINDING PROTECTION FLOOR F-1

Low Voltage Motor, 208-230/460V, 60 Hz, 3PH, 12.5A, 1755 RPM, 215T Frame, Class F

LOW-VOLTAGE MOTOR, NEMA 3 PHASE SQUIRREL CAGE MOTOR GENERAL PURPOSE GP100 CAST-IRON HOUSING NP EFFICIENCY TEFC (IP54) 4 POLE * FS 324T 40 HP (60 HZ) 230/460V STD 60HZ FOOT MOUNTED F-1,2 WITHOUT WINDING PROTECTION FLOOR F-1 B09=EXPORT PACKING SIEMENS STANDARD

LOW-VOLTAGE MOTOR, NEMA 3 PHASE SQUIRREL CAGE MOTOR GENERAL PURPOSE GP100 CAST-IRON HOUSING NP EFFICIENCY TEFC (IP55) 4 POLE * FS 143T 1 HP (60 HZ) 230/460V, 60HZ (suitable for 208V) C-FACE WITH FEET WITHOUT WINDING PROTECTION FLOOR F-1

SD motor type: 1CV3184D low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Performance Line Premium Efficiency IE3, 8-pole * size 180L, * 11 kW (50 Hz) standard color RAL 7030 if no order code is specified for selecting another color. The product will be delivered with either the Siemens or Innomotics product brand.

SIMOTICS SD motor type: 1CV3312B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line Premium Efficiency IE3, in EEA: minimum efficiency according to (EU) 2019/1781 is IE4 (as of 01.07.2023) 4-pole * size 315M, *132 kW (50 Hz/60 Hz) 152 kW (60 Hz)

SD motor type: 1CV3310B low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing Basic Line IE3, NEMA Premium, CSA, UL, in EEA: minimum efficiency according to (EU) 2019/1781 is IE4 (as of 01.07.2023) 4-pole * size 315S, * 110 kW (50 Hz) NEMA 60 Hz: 150 HP standard color RAL 7030 if no order code is specified for selecting another color. The product will be delivered with either the Siemens or Innomotics product brand. 3 AC 50Hz 415VD * 3 AC 60 Hz 480 VD IM B 35 * Flange: FF600 (A660) 3 PTC thermistors for disconnection (2 terminals) Terminal box at top
