Specs at a glance
Input: 1x Puls/Analog for flow
2x RTD/Analog for temperature and pressure
Loop power supply 24V DC (+/-16%)
Output: 1x 4…20mA
2x digital (Open Collector)
Display: 160 x 80 Dot-Matrix LCD with white backlit
colour change in case of alarm event
active display area 70 x 34 mm
Calculations: IAPWS-IF97
—————————————-
Field of application
Endress Hauser’s
The steam calculator EngyCal RS33 is used to record steam mass and energy flow of saturated and superheated steam. The calculation is based on the measured process variables volume flow, temperature and/or pressure.
The EngyCal RS33 uses the standard IAPWS IF97 to calculate the mass and energy flow of steam. The density and enthalpy of the steam are calculated from the input variables pressure and temperature.
• Food industry
• Chemical industry
• Pharmaceutical industry
• Power plants
• Building systems and plant engineering
