Specs at a glance
Accuracy: Class A acc. to IEC 60751
Class B acc. to IEC 60751
Class standard acc. to ASTM E230
Class 2 acc. to IEC 60584-2
Response time: t90 around 17 s
depending on configuration
Max. process pressure (static): depending on the configuration
Operating temperature range: Basic PT100 TF:
-50 °C …200 °C
(-58 °F …392 °F)
Typ K:
max. 1.100 °C
(max. 2.012 °F)
Max. immersion length on request: up to 1.000,0 mm (39”)
—————————————-
Field of application
Basic thermometers offer reliable temperature measurement performance with basic sensor technology, a standard extension neck and a fixed, non-replaceable insert for use in non-hazardous areas. The devices are available with optional Bluetooth®-enabled head transmitters with 4 to 20 mA output or HART® communication, providing enhanced measurement accuracy and reliability compared to directly wired sensors.
• Wide range of applications
• Measuring range: -50 to +650 °C (-58 to +1202 °F)
• Pressure range: up to 50 bar (725 psi)
• Protection class: up to IP68
• For use in non-hazardous areas
