LPGmass D8EB Coriolis flowmeter

Specs at a glance

Max. measurement error: Mass flow (liquid): ±0.20 %
Volume flow (liquid): ±0.30 %
Measuring range: 0 to 70 000 kg/h (0 to 2570 lb/min)
Medium temperature range: –50 to +125 °C (–58 to +257 °F)
Max. process pressure: PN 40, Class 300
Wetted materials: Measuring tube: 1.4539 (904L)
Connection: 1.4404 (316/316L)

—————————————-

Field of application

The LPGmass is specially designed for flow measurement of LPG for dispensing and truck unloading. It combines an integrated temperature measurement with intelligent conversion functions, providing volume correction directly on site. LPGmass will be the preferred choice for system integrators, skid builders and equipment manufacturers.

• Measuring principle operates independently of physical fluid properties such as viscosity or density
• Accurate measurement of liquefied petroleum gas in refueling and distribution applications.
• Flow rates up to 70 000 kg/h (2570 lb/min)
• Volume flow calculation according to API table 53
• Robust, compact transmitter housing
• Modbus RS485
• Designed to meet application needs

Device properties
