Magphant electromagnetic flowmeter

Specs at a glance

Max. measurement error: 2%
Measuring range: 0 to 56’550 m3/h
Medium temperature range: -20 to +120°C
(-4 to +248°F)
Max. process pressure: 0 to 16 bar abs
Wetted materials: 1.4435/316L

—————————————-

Field of application

The cost-effective, compact limit switch Magphant is an ideal flowmeter for water applications in Utilities. Its reliable measurement with high repeatability allows for univesal and easy use and supports safe process- and plant operation.

• The bidirectional measuring principle is virtually independent of pressure, density, temperature and viscosity
• Universally usable for all water applications in Utilities.
• Compact, space-saving design
• Nominal diameter: DN 15 to 2000 (1/2 to 80″)
• Applicable for steel or plastic pipes
• Switch point setting via rotary switch
• Current output and relay output
• ATEX, FM, CSA

Device properties
