Proline Prosonic Flow 92F ultrasonic flowmeter

Specs at a glance

Max. measurement error: Volume flow (standard):
– ±0.5 % o.r. for 0.5 to 10 m/s (1.6 to 33 ft/s)
Volume flow (option):
– ±0.3 % o.r. for 0.5 to 10 m/s (1.6 to 33 ft/s)
Measuring range: 0.5 to 10 m/s (1.6 to 33 ft/s)
Medium temperature range: -40 to +150 °C (-40 to +302 °F)
-40 to +200 °C (-40 to +392 °F) optional
Max. process pressure: PN 40 / ASME Cl. 300 / JIS 20K
Wetted materials: Sensor:
A351-CF3M (DN25 to 100)
1.4404/TP316/TP316L or A106 GrB (DN150 to 300)
Transducer: 1.4404/316/316L
Flanges : 1.4404/316/316L or A105/1.0432

—————————————-

Field of application

Prosonic Flow F is the inline sensor with rugged industrial design for Ultrasonic fluid measurement. Combined with the loop-powered Prosonic Flow 92 transmitter, the device offers easy system integration and accuracy at an attractive price. Prosonic Flow 92F is ideally suited for the chemical and petrochemical industries.

• The measuring principle is independent of pressure, density, temperature, conductivity and viscosity
• Inline device for homogeneous conductive and non-conductive liquids in the chemical and petrochemical industry
• Full compliance according to NACE MR0175 and MR0103
• Nominal diameter: DN 25 to 300 (1 to 12″)
• Medium temperature: –40 to 200 °C (–40 to 392 °F)
• Device as compact or remote version
• 2-line backlit display with push buttons
• HART, PROFIBUS PA, FOUNDATION Fieldbus

Device properties:
