Telemecanique Sensors XS118B3PAM12 L50mm-Sn8mm M18 Inductive Sensor

Product Range Telemecanique Inductive Proximity Sensors XS
Serial Name For General Purpose
Sensor type inductive proximity sensor
Device Application Mobile Equipment
Sensor Name XS1
Sensor design cylindrical M18
Size 50 mm
Body type fixed
Detector Burging Assembly Acceptance Burial Assembly
Material metal
Output signal type
Wiring Technique 3 Strong
[SN] Nominal Perception Distance 8 mm
Discriminated output function 1 no
Output circuit type DC
Discrete output type PNP
Electrical Connection Men’s Connector M12, 4 Pin
[US] Nominal Feeding Voltage 12 … 24 V DC, Reverse Polarity Protected
Switching capacity in MA <= 200 mA, overload and short circuit protected IP65 Compliance IP65 IEC 60529 IP67 Compatibility IEC 60529
