Telemecanique Sensors XS7C4A1MPG13 SN15mm 40x40x117 Inductive Sensor

MAIN
Product range telemecanique xs inductive affinity detectors
December Name Evrensel
Sensor type inductive proximity sensor
Sensor Name XS7
Sensor shape Figure 40x40x117
Size 117 mm
Storage type fixed
Detector assembly capacity
Subject Plastic
BOX MATERIAL PBT
Output signal type digital
Connection Method 2 Son
[SN] Nominal December 15mm
Logic Output 1 “O” or 1 “C” programmable
Output circuit type AC/DC
Electrical Connection Screw Clamp Terminals, 4 x 1.5 mm²
[USA] Nutrition Voltage 24… 240 V AC 50/60 Hz
24… 240 V DC
Switching capacity in MA 5… 200 MA DC
5… 300 mA ac
IP protection degree IP67 compatible IEC 60529
IP65 compatible IEC 60529
IP69K compatible DIN 40050
COMPLEMENT
Perception face 5 -position notch title
Front panel material PBT
Working range 0… 12 mm
3 %of the differential road SR
Repeat accuracy <= 3 %of the SR Cable input number PG13.5 1 Piece for Cable Rakor LED Status Power Open: 1 LED (Green) Output Status: 1 LED (Yellow) Feeding voltage limits 20… 264 VAC/DC Maximum current current 1.5 mA is open status 120 V 0.6 MA Open Status 24 V Frequency Change <= 25 Hz AC <= 50 Hz DC Maximum voltage drop <5,5V (closed) Maximum usability delay 7,5MS Maximum response delay 1.2 ms Maximum recovery delay 1.8 ms Height 40mm Length 40mm Width 117 mm Product weight 0.244 kg
