Schneider ATV310HD15N4E 15KW speed controller

Product Features
Product series
:
Easy Altivar 310
Product or component type
:
Variable Speed ​​Driver
Product Special Application
:
Simple machine
Assembly style
:
Cooling block
Product group
:
ATV310
Network Network of Phase
:
Trifase
[US] Nominal Nutrition Voltage
:
380 … 460 V – 15 … 10
Motor Power KW
:
15 kW
Motor Power HP
:
20 hp
Noise level
:
50 DB
Complementary features
Product destination
:
Asynchronous motors
Quantity per set
:
1 set
EMC filter
:
Without EMC Filter
Type of cooling
:
Integrated fan
Feeding frequency
:
50 60 Hz – 5
Communication Port Protocol
:
Modbus
Type of the connector
:
Modbus for RJ45 (front percentage)
Physical interface
:
Modbus for 2 stringed RS 485
Transmission frame
:
Modbus for RTU
Transmission rate
:
4800 bit SN
9600 bit S
19200 bit S
38400 bit sec
Number of Addresses
:
Modbus for 1 247
Communication service
:
Read waiting records (03) 29 Word
Write Single Records (06) 29 Word
Write Multiple Records (16) 27 Word
Read Multiple Records Write (23) 4 4 Word
Read Device Definition (43)
Line flow
:
46.5 A
Visible power
:
30.7 kva
Possible line ISC
:
22 ka
Continuous output current
:
33 A -DE 4 KHZ
Maximum temporary current
:
60 s for 49.5 A
Power distribution in W
:
In 438.8 W IN
Speed ​​control device output frequency
:
0.5 400 Hz
Nominal switching frequency
:
4 KHz
Switching frequency
:
2 … 12 khz adjustable
Speed ​​range
:
1 20
Temporary Moment
:
170 Nominal Motor Torku depending on 200 drive value and engine type
Braking torque
:
Up To 150 Of Nominal Motor Torque with high braking resistance in high inertia
Without the braking resistance up to 70 of the nominal motor torque
Asynchronous motor control profile
:
Square voltage frequency ratio
Sensor -free flux vector control
Square voltage frequency ratio
Motor slip compensation
:
Available in the factory
Adjustable
Output voltage
:
380 … 460 V Trifase
Electric connection
:
Terminal, Clamping Capacity: 10 mm² (L1, L2, L3, PA, PB, U, V, W)
Squeezing torque
:
2.2 2.4 N.M
Insulation
:
Electricity between power and control
Supply
:
Internal feeding for reference potentiometer: 5 V (4,75 5.25 V) DC, 10 mails overload and short circuit protection
Internal feeding for logic inputs: 24 V (20.4 28.8 V) DC, 100 mails overload and short circuit protection
Number of analog inputs
:
1
Analog input type
:
Configurated current AI1 0 … 20 MA 250 OHM
Configurated voltage AI1 0 … 10 V 30 Kohm
Configurated voltage AI1 0 … 5 V 30 Kohm
Number of digital inputs
:
4
Digital entry type
:
Programmable LI1 … LI4 24 V 18 … 30 V
Digital entrance logic
:
Negative Logic (Block), 16 V (Case 0), 10 V (Case 1), Integration Impedance 3.5 Kohm
Positive Logic (Source), 0 … 5 V (Status 0), 11 V (Status 1)
Sampling time
:
Analog input for 10 ms
20 ms, tolerance – Logic input for 1 ms
Linearity error
:
Analog input for maximum value – 0.3
Analog output number
:
1
Analog output type
:
AO1 Software-Related Voltage: 0 … 10 V, Impedance: 470 ohm, resolution 8 bit
AO1 Software-Related Current: 0 … 20 MA, Impedance: 800 ohm, resolution 8 bit
Digital output number
:
2
Digital output type
:
Lojic output lo-
Protected Relay Output R1A, R1B, R1C 1 K a
Minimum switching current
:
Logic relay for 24 V DC
Maximum switching current
:
2 A -DE 250 V AC inductive load cos phi 0.4 l r 7 msn logic relay
2 A -DE 30 V DC inductive load cos phi 0.4 l r 7 msn logic relay
3 A -DE 250 V AC resistant load Cos Phi PHi 1 l R 0 msn logic relay
4 A -de 30 V DC resistant load cos phi 1 l R 0 msn logic relay
Acceleration and slowing ramps
:
U
S
Linear from 0 … 999.9 S
Braking until it stops
:
With DC Injection, 30 S
Protection type
:
Line feeding excess voltage
Low Feeding Low voltage
Over Current Between Output Phase and Soil
Protection against overheating
Short circuit between motor phases
Against the Loss of Entry Phase in Trifase
Thermal motor protection over the driver with continuous calculation of I²T value
Frequency resolution
:
Analog input: Converter A D, 10 bit
Screen Unit: 0.1 Hz
Time constant
:
20 ms – For 1 ms reference change
Working position
:
Vertical – 10 degrees
Height
:
330 mm
Width
:
180 mm
Depth
:
191 mm
Product weight
:
6.3 kg
